Butterfly Valves |M-Line

Highest certification standards and universal media compatibility

M-Line series – Certified soft-seal butterfly valves for water, gas and industrial applications

Absperklappe P-Line

The soft-sealing centrifugal butterfly valves of the M-Line series offer uncompromising quality and safety for highly sensitive and regulated sectors. Thanks to comprehensive approvals such as DVGW (for drinking water and gas), WRAS and FDA, they are perfectly suited to the water sector, gas supply, and the food and chemical industries.

The M-Line covers nominal diameters from DN32 to DN1600 and, thanks to a wide range of seal materials (such as NBR, EPDM, FKM, silicone or CSM), it offers optimal adaptation to the respective medium. Complemented by an ATEX approval (Group II, Category 1/2 GD up to Zone 0/20 indoors) and the standard ISO 5211 direct mounting for actuators, this series is universally applicable in process automation.

Technical Specifications & Key Features

Design

  • Centric wafer and lug type butterfly valves
  • 2-piece shaft
  • EN-ISO 5211 direct mounting

Nominal diameters

  • DN32 ... DN1600

Operating pressure

  • Up to 16 bar

Temperature range

  • Up to +150 °C
    (Depending on pressure, medium, and material combination)

Variety of elastomers and materials

  • NBR · EPDM · XNBR · FKM · Silicone · ECO · CSM, among others
    (Numerous body and disc materials available)

Media resistance

  • PTFE/PFA lining for aggressive and corrosive media

Approvals

  • DVGW Drinking Water · DVGW Gas · WRAS · FDA
  • ATEX Group II, Category 1/2 GD – up to Zone 0/20 indoors
